Item No: 228783

Hard rubber distributor box, type 7300, black

7300.8291411.M.M25/1 - CG at the bottom

Technical data

Output plug
  • T23
  • T25
  • CEE 16/5
max. pre-fuse
40 A
Input of cable gland(s)
M25
Position of cable gland(s)
below
Width
200 mm
Height
350 mm
Depth
134 mm
Type
7300
Protection rating
IP44
Case material
solid rubber
Characteristics hard rubber
Hard Rubber:
  • fully insulated
  • impact resistant
  • UV resistant
  • halogen-free
  • aging and temperature resistance
  • oil-and acid-resistant
  • fire resistant
  • self extinguishing
  • good chemical resistance
Case colour
black
Fixation
4 internal, separated assembly channels for wall mounting
Additional equipment
with protective cover and protective cap
Output
2xT23, 1xT25, 1xCEE 16/5
