Small hard rubber distributor box type 2812, black

Technical data

Output plug

• T23
• T25

max. pre-fuse

16 A

Input of cable gland(s)

M20

Position of cable gland(s)

below

Width

120 mm

Height

269 mm

Depth

133 mm

Type

2812

Protection rating

IP55

Case material

solid rubber

Characteristics hard rubber

Hard Rubber:

• fully insulated
• impact resistant
• UV resistant
• halogen-free
• aging and temperature resistance
• oil-and acid-resistant
• fire resistant
• self extinguishing
• good chemical resistance

Case colour

black

Output

2xT23, 2xT25

Downloads

Dimensional drawing/Scheme

Accessories

Item No: 016382

Countersunk screw A2 - M5x12mm

with hexagon socket

Item No: 050109

Automated unit protective caps 4 modules,

(82mm)

Item No: 041180

Monting bracket, rust-free, VA4 for type 2812

310x15x3mm
